Product Description

Merriott’s SMART Radiant Panels offer a discreet and energy-efficient alternative to standard wall or floor mounted radiators. Merriott’s diverse radiant portfolio has been tested in accordance with EN14037 and caters for every project requirement, whilst providing energy savings of up to 40%.

How Radiant Panels Work

Unlike convection heaters which rely on air circulating through the radiator to warm the room, Radiant Panels provide instant infra-red heat directly to anyone or anything in close proximity. Radiant heat from the panel warms objects in the room, which in turn act as a secondary heat source. Quick system response time enables a building to operate at a reduced air temperature whilst maintaining the same level of comfort, resulting in lower energy consumption.

Visually, the Radiant Panel can be customised to fit the environment of any project. Flat and perforated finishes are available in over 200 RAL colours, with the option to incorporate features such as lights, vents, speakers, sprinklers and much more. Selected SMART models are fitted either in multiple strips or in series to create sails or even full metal ceilings (FMCs).

The versatility of the SMART panels makes them ideal for any application such as classrooms, commercial spaces, healthcare wards, large sports arenas, aircraft hangars, train depots and even industrial facilities.

Each of our SMART Radiant Panels has its own unique features:

SMART – Designed for use within a 600mm ceiling grid, the SMART radiant panel is suitable in both standard and micro T-grid ceiling systems. Panels are available in nominal sizes and can replace up to five ceiling tiles at a time. Special versions of the SMART are available for free hanging and plasterboard applications. Boasting market-leading performance, the SMART offers a UK-manufactured, cost-effective heating solution with an impressive technical specification.

SMART HD – Available in widths from 300mm to 1500mm and lengths stretching as far as 100 metres, the SMART HD (Heavy Duty) is best suited to large industrial projects and commercial areas such as aircraft hangars, factories and sports halls. The SMART HD is steel manufactured using 28mm diameter waterways, allowing higher flow rate and lower pressure loss. The panel also comes complete with crimp fittings for straightforward installation. Choose between a perforated or smooth panel finish in our standard RAL 9016 white, or in any other of our 200+ RAL colours.

Outputs

Radiant Panel
edge

HD Radiant Panel
edge

Installation Instructions

Download SMART Installation Instructions

Download SMART HD Installation Instructions

Brochures





Case Study

edge

Warranty

6.1. Save as expressly provided in these Conditions and except where the Goods are sold to a person dealing as a consumer (within the meaning of the Unfair Contract Terms Act 1977) all warranties, conditions or other terms implied by statute or common law are excluded to the fullest extent permitted by law.

6.2. Subject to clauses 6.3, 6.4 and 6.5, the Seller warrants that the Goods will correspond with all relevant British Standards and adopted International Standards and be free from defects in material and workmanship at the time of their delivery and for a period of:

- 10 years - Precision, Profile, Multi-column, Ultima, Protecta, Primo, Primo Plus, Fascia, Fascia Grace, Fascia Vertical, Optima and Centre Tap ranges.

- 5 years - HD radiant panel, SMART radiant panel, Radiavector, Crystal, Crystal E, Edge & Groove ranges.

- 2 years - Electrical componentry forming part of electrified radiators and towel warmers

6.3. The Sellers warranty as aforesaid:

6.3.1. shall be conditional upon the Buyer notifying in Writing all and any defects apparent at the time of delivery to the Seller within 48 hours of the time of delivery of the Goods by the Seller; and

6.3.2. does not extend to Goods for which the Price has not been paid by the due date or to parts, materials or equipment not manufactured by the Seller. If the Goods have not been manufactured by the Seller the Seller will use its reasonable endeavors to pass to the Buyer the benefit of any warranty or guarantee afforded to the Seller by the manufacturer of such item ·where such warranty or guarantee is capable of assignment.

6.4. For the purposes of clause 6.3 a defect shall be apparent at the time of delivery if it would have been so apparent upon a reasonably thorough examination and inspection of the Goods by the Buyer (whether or not such examination or inspection is actually made by the Buyer).

6.5. The Seller shall not be liable for defects in the Goods arising from any drawing design or specification supplied by the Buyer or for defects arising from wear and tear, damage, negligence, abnormal working conditions, failure to take adequate measures to protect the Goods from damage, incorrect handling or storage, failure to follow the Sellers instructions (whether oral or in Writing) mis-use, alteration or repair of the Goods without the Sellers prior approval in Writing.
